BTEC Level 3: As part of your engineering apprenticeship training you have been moved to your company’s design department to gain further experience: Unit 8 Mechanical Principles of Engineering Systems, Assignment, UOW, UK

Scenario

As part of your engineering apprenticeship training you have been moved to your company’s design department to gain further experience. Part of your new role will involve assisting with calculations and the chief designer wants to assess your abilities by giving you a test.

Task 1

A component is subjected to the forces as shown in the diagram.

(a). Calculate the forces and moments then copy and complete the table for the force system shown above.

(b). Determine the magnitude and the direction of the resultant of the forces shown in the above diagram.

(c) State the three conditions required for static equilibrium in a two-dimensional system.

(d) State the magnitude and direction of the equilibrant.

(e) Define the moment of a force about a particular point.

(f) Determine the position of the equilibrant.
